ONKYO TX-SR309 5.1-CHANNEL HOME THEATER RECEIVER

$369.00

Onkyo presents the TX-SR309—an entry-level A/V receiver fine-tuned to power your system right out of the box. Set-up is simple and adjustments are easy, thanks to a new overlaid on-screen display. Also new at this level is PLL jitter-cleaning circuit technology to reduce distortion, and a front-panel USB port that provides a high-quality digital link to your iPod/iPhone. To get the best from your compressed audio files, the TX-SR309 employs Onkyo’s proprietary Advanced Music Optimizer. Naturally, the receiver also handles high-def, lossless audio in the form of Dolby® TrueHD and DTS-HD Master Audio. These are carried by three HDMI® inputs that also support immersive 3D video content. And whether you’re gaming in 3D or not, you can choose from four customized audio modes to match your gaming content. It all adds up to one high-value proposition.

Add to wishlist
Share
Categories,
Tag
    Front L/R 65 W/Ch (8 ohms, 20 Hz–20 kHz, 0.7%, 2 channels driven, FTC) 90 W/Ch (6 ohms, 1 kHz, 0.9%, 2 channels driven, FTC
    Center 65 W (8 ohms, 20 Hz–20 kHz, 0.7%, 2 channels driven, FTC) 90 W (6 ohms, 1 kHz, 0.9%, 2 channels driven, FTC)
    Surround L/R 65 W/Ch (8 ohms, 20 Hz–20 kHz, 0.7%, 2 channels driven, FTC) 90 W/Ch (6 ohms, 1 kHz, 0.9%, 2 channels driven, FTC)
    Dynamic Power 160 W (3 ohms, Front)

    125 W (4 ohms, Front)

    85 W (8 ohms, Front)

    THD+N (Total Harmonic Distortion + Noise) 0.08% (20 Hz–20 kHz, Half power)
    Damping Factor 60 (Front, 1 kHz, 8 ohms)
    Rated RCA Output Level and Impedance 200 mV/2.2 k-ohms (Rec out)
    Input Sensitivity and Impedance 200 mV/47 k-ohms (Line)
    Frequency Response 20 Hz–50 kHz/+1 dB, -3 dB (DSP bypass)
    Tone Control ±10 dB, 50 Hz (Bass)

    ±10 dB, 20 kHz (Treble)

    Signal-to-Noise Ratio 100 dB (Line, IHF-A)
    Speaker Impedance 6 ohms–16 ohms
    Input Sensitivity/Output Level and Impedance
    • Video

    1.0 Vp–p/75 ohms (Component)

    0.7 Vp–p/75 ohms (Component PB/CB, PR/CR)

    1.0 Vp–p/75 ohms (Composite)

    • Component Video Frequency Response

    5 Hz–100 MHz/0 dB, -3 dB

    Tuning Frequency Range FM – 87.5 MHz–107.9 MHz

    AM – 530 kHz–1,710 kHz

    FM/AM – Preset Memory 40 stations

    Power Supply AC 120 V~, 60 Hz
    Power Consumption 3.3 A
    Dimensions (W x H x D) 17 1 /8˝ x 5 7 /8˝ x 12 15/16˝

    (435 x 150 x 328 mm)

    Weight 16.5 lbs. (7.5 kg)
